How to Inspect the Engine Air Filter in your 2021 Bronco

David
Oct 21, 2021

Rank VI

Oct 21, 2021

Bronco engines pull in A LOT of air. The turbo that gives sixth generation Broncos their zip is a thirsty component and if you're doing a lot of off-roading in dusty environments, you'll want to keep an eye on the engine air filter. Here's how to inspect it and how often you should.

How often should I check the engine air filter on a new Bronco?

The Bronco owner's manual suggests that the filter be replaced every 30,000 miles. However, if you keep reading, it suggests that if you are driving in dusty or sandy conditions, such as on unpaved or dirt roads, then you should inspect it frequently and service as required. To me, the point of a Bronco is to spend as much time as possible in those very conditions so you'll want to be inspecting that filter a lot.

In our recent trip to Colorado for Bronco Super Celebration West, we did a solid two weeks of off-roading and when we checked our air filter, it was in need of replacement and we were right around 10K miles on the odometer. Now, the number of folks who do that kind of driving are small but if you're out doing what Broncos are made to do, we'd suggest checking this filter frequently. It takes about five minutes and it's much better than dealing with a severely damaged engine.

How do I inspect the engine air filter on the new Bronco?

Tools Required:
  1. Ratchet
  2. 5/16th Socket
To inspect your engine air filter, follow these steps:
  1. Pull the hood release handle under the left-hand side of the instrument panel.
  2. Release the hood latch by pushing the secondary release lever to your left-hand side.
  3. Open the hood and support it with the hood strut.
  4. Identify the air filter housing cover in the lower left-hand portion of the engine bay. (labeled H in figure 1)
  5. Remove the four screws from the air filter housing cover (see figure 2)
  6. Carefully lift the air filter housing cover.
  7. Inspect the air filter and air filter housing.
    • The filter housing should be generally free of debris and dust build up.
    • Paper filter elements are usually white or yellow. When they become gray, meaning they are full of dirt and dust, it is time to change.
    • See figure 3 for an example of a filter that needs replacement and figure 4 for a clean, new filter.
  8. Once you've inspected the filter, replace the air filter housing cover and close the hood.
Notes and Considerations (from the owners manual):
  • Failure to use the correct air filter element could result in severe engine damage that the vehicle warranty may not cover.
  • When servicing the air cleaner, do not allow foreign material to enter the air induction system. The engine is susceptible to damage from even small particles.
  • To reduce the risk of vehicle damage and personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Figure 1:

Screen Shot 2021-10-21 at 1.17.14 PM.png

Figure 2:

Screen Shot 2021-10-21 at 1.10.34 PM.png

Figure 3:


Figure 4:

Bronco Nation Member #144
David in the Bronco Nation Forums
BroncoTroubadour on Instagram
RJames, Mattwings

Rank VII

Oct 21, 2021

#1
Thanks for posting. This is really an important post.
Bronco Nation Member #0000
Instagram: bdawson24
BuckYeah, Bronco*girl66

Your unofficial Favorite Author

Oct 21, 2021

#2
Cant wait to install a kn filter there
2dr Badlands 2.3 Manual w/Mid, Rapid Red
My blog, Mfcomics.net, my stories: https://payhip.com/MFComics
LR48, thehatrix

Custom Title

Oct 21, 2021

#3
Good stuff, I give it 5 horse shoes.
SuzHansen, LR48

Rank VI

Oct 22, 2021

#4
Bronco engines pull in A LOT of air. The turbo that gives sixth generation Broncos their zip is a thirsty component and if you're doing a lot off-roading in dusty environments, you'll want to keep an eye on the engine air filter. Here's how to inspect it and how often you should.

How often should I check the engine air filter on a new Bronco?

The Bronco owner's manual suggests that the filter be replaced every 30,000 miles. However, if you keep reading, it suggests that if you are driving in dusty or sandy conditions, such as on unpaved or dirt roads, then you should inspect it frequently and service as required. To me, the point of a Bronco is to spend as much time as possible in those very conditions so you'll want to be inspecting that filter a lot.

In our recent trip to Colorado for Bronco Super Celebration West, we did a solid two weeks of off-roading and when we checked our air filter, it was in need of replacement and we were right around 10K miles on the odometer. Now, the number of folks who do that kind of driving are small but if you're out doing what Broncos are made to do, we'd suggest checking this filter frequently. It takes about five minutes and it's much better than dealing with a severely damaged engine.

How do I inspect the engine air filter on the new Bronco?

Tools Required:
  1. Ratchet
  2. 5/16th Socket
To inspect your engine air filter, follow these steps:
  1. Pull the hood release handle under the left-hand side of the instrument panel.
  2. Release the hood latch by pushing the secondary release lever to your left-hand side.
  3. Open the hood and support it with the hood strut.
  4. Identify the air filter housing cover in the lower left-hand portion of the engine bay. (labeled H in figure 1)
  5. Remove the four screws from the air filter housing cover (see figure 2)
  6. Carefully lift the air filter housing cover.
  7. Inspect the air filter and air filter housing.
    • The filter housing should be generally free of debris and dust build up.
    • Paper filter elements are usually white or yellow. When they become gray, meaning they are full of dirt and dust, it is time to change.
    • See figure 3 for an example of a filter that needs replacement and figure 4 for a clean, new filter.
  8. Once you've inspected the filter, replace the air filter housing cover and close the hood.
Notes and Considerations (from the owners manual):
  • Failure to use the correct air filter element could result in severe engine damage that the vehicle warranty may not cover.
  • When servicing the air cleaner, do not allow foreign material to enter the air induction system. The engine is susceptible to damage from even small particles.
  • To reduce the risk of vehicle damage and personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Figure 1:

View attachment 20062

Figure 2:

View attachment 20063

Figure 3:

View attachment 20064

Figure 4:

View attachment 20065
Thank You! Such a critical part of regular maintenance. I'm really surprised that K&N hasn't developed an after market replacement filter. I've used K&N filters in all of my vehicles on and off road for years and found them to be exceptional, both in filtration, performance and the ability to clean and reuse. Apparently they're asleep at the switch, nothing on their website.
wmneill, SquatchOrBust

Your unofficial Favorite Author

Oct 22, 2021

#5
Thank You! Such a critical part of regular maintenance. I'm really surprised that K&N hasn't developed an after market replacement filter. I've used K&N filters in all of my vehicles on and off road for years and found them to be exceptional, both in filtration, performance and the ability to clean and reuse. Apparently they're asleep at the switch, nothing on their website.

They'll get to it, ya know how wonky things have been with Ford lately
2dr Badlands 2.3 Manual w/Mid, Rapid Red
My blog, Mfcomics.net, my stories: https://payhip.com/MFComics
wmneill

Rank VI

Oct 22, 2021

#6
Thank You! Such a critical part of regular maintenance. I'm really surprised that K&N hasn't developed an after market replacement filter. I've used K&N filters in all of my vehicles on and off road for years and found them to be exceptional, both in filtration, performance and the ability to clean and reuse. Apparently they're asleep at the switch, nothing on their website.

They'll get to it, ya know how wonky things have been with Ford lately

Yep I know they will, I’m sure along with great filter options as always they’ll have some very good performance kits for the 2.7. Of course I don’t know why I’m in a rush my Wildtrak is now MY22.
wmneill, Speed Devil

Your unofficial Favorite Author

Oct 22, 2021

#7
Yep I know they will, I’m sure along with great filter options as always they’ll have some very good performance kits for the 2.7. Of course I don’t know why I’m in a rush my Wildtrak is now MY22.

I'm supposedly next month, hopefully it arrives BEFORE my birthday (12/12) or the birth of my nephew (12/8)
2dr Badlands 2.3 Manual w/Mid, Rapid Red
My blog, Mfcomics.net, my stories: https://payhip.com/MFComics
LR48

Gladesmen

Oct 22, 2021

#8
Thank You! Such a critical part of regular maintenance. I'm really surprised that K&N hasn't developed an after market replacement filter. I've used K&N filters in all of my vehicles on and off road for years and found them to be exceptional, both in filtration, performance and the ability to clean and reuse. Apparently they're asleep at the switch, nothing on their website.
Just a question but any of those vehicles have turbos? I have heard the K&N will let too much particles go through when they are new/clean they actually work better when they have some dirt on them. I have heard you can dust your turbo if you run a K&N. Maybe a pre-filter would help.
Bronco Nation 1100. Everglades, Desert Sand
Res: 7/30/20 ordered 1/22/21 reorder 10/15/21 changed to Everglades 3/9/22 schedule 8/29/22 bumped to 9/5; 9/7/22 blend, 9/9 Mods, 9/26/22 completed, 10/7 shipped, 11/3/22 delivery
Hans

Rank V

Oct 22, 2021

#9
Good info . Is there a cabin filter, even if its supposed to be a open air experience
202X Wildtrak, Area 51, Tow, Lux.MIC. Build date Dec.19 2022
hoping delivery for my birthday Feb 22!!! Received Feb 13 2023.
Speed Devil

Rank VI

Oct 22, 2021

#10
Just a question but any of those vehicles have turbos? I have heard the K&N will let too much particles go through when they are new/clean they actually work better when they have some dirt on them. I have heard you can dust your turbo if you run a K&N. Maybe a pre-filter would help.
I wouldn’t use a K&N. First of all, there’s no point to it - the engine has a turbo, and can ingest as much air as it needs. Secondly, the K&N lets too many small particles through, which is likely to damage the turbo or the MAF sensor.
As for putting a pre-filter in front of the K&N, well - that’s defeating the whole point of the K&N, which is to permit better air flow.
(FWIW, I used a K&N in my 1986 Mustang GT, and didn’t detect any difference in performance at all).
Bronco*girl66, Milkbaby

Rank VI

Oct 23, 2021

#11
Yes there is a cabin air filter. Recommend change at 20,000 miles. Like engine air filter, plan to change a lot more often. Hope K&N brings out a washable cabin filter.
Bronco*girl66, TK1215

Rank V

Oct 23, 2021

#12
A 5/16” socket.!?? Seriously? I’m gonna have to see that.! LOL.! (my money says it’s mm) Thanks for reminding everyone of this important service item. The pics and diagrams are awesome.!
F ederal O wnership R espectfully D eclined

Rank VI

Oct 23, 2021

#13
Good info . Is there a cabin filter, even if its supposed to be a open air experience

There is a cabin filter, I don’t think it supposed to be user serviceable but I’m looking into it.
Bronco Nation Member #144
David in the Bronco Nation Forums
BroncoTroubadour on Instagram
Bronco*girl66

Rank VI

Oct 23, 2021

#14
A 5/16” socket.!?? Seriously? I’m gonna have to see that.! LOL.! (my money says it’s mm) Thanks for reminding everyone of this important service item. The pics and diagrams are awesome.!

Could be, I used a 5/16s but ¯\_(ツ)_/¯
Bronco Nation Member #144
David in the Bronco Nation Forums
BroncoTroubadour on Instagram
Deano Bronc, Jakob1972

Rank VI

Oct 23, 2021

#15
Cabin Air Filter: Owner's Manual does not reveal where it is located or how to change it. On some other vehicles it is behind the glove box.
Bronco*girl66

Rank VI

Oct 23, 2021

#16
Just a question but any of those vehicles have turbos? I have heard the K&N will let too much particles go through when they are new/clean they actually work better when they have some dirt on them. I have heard you can dust your turbo if you run a K&N. Maybe a pre-filter would help.
I know that the Ford off-road teams all use K&N filters and I have used them in various off road motorcycles and vehicles for years without any negative results. Proper prep is the key and using the usually included oil for the filter is important, especially after you wash them. I've never ingested anything with any of them. I'm quite sure there will be a complete performance kit available in short order for 2.3 and 2.7 which will include rerouted intake plumbing etc.
Bronco*girl66, jimFish

Custom Title

Oct 23, 2021

#17
A 5/16” socket.!?? Seriously? I’m gonna have to see that.! LOL.! (my money says it’s mm) Thanks for reminding everyone of this important service item. The pics and diagrams are awesome.!
5/16 and 8 mm interchange.
RJames, Bronco*girl66

Rank V

Oct 24, 2021

#18
5/16 and 8 mm interchange.
Just so everyone will know which MM wrench/SAE wrench will work when you're in a bind.! Check out the 19mm…it’s a perfect 3/4”..!8E39A602-7321-422C-8194-433146A04FD7.jpeg
F ederal O wnership R espectfully D eclined
BuckYeah, Bronco*girl66

Gladesmen

Oct 24, 2021

#19
I know that the Ford off-road teams all use K&N filters and I have used them in various off road motorcycles and vehicles for years without any negative results. Proper prep is the key and using the usually included oil for the filter is important, especially after you wash them. I've never ingested anything with any of them. I'm quite sure there will be a complete performance kit available in short order for 2.3 and 2.7 which will include rerouted intake plumbing etc.
I have used K&N filters on many of my vehicles I just never used one on a turbo after getting my diesel and reading all the forums talk about the K&Ns. If always used BHAFs
Bronco Nation 1100. Everglades, Desert Sand
Res: 7/30/20 ordered 1/22/21 reorder 10/15/21 changed to Everglades 3/9/22 schedule 8/29/22 bumped to 9/5; 9/7/22 blend, 9/9 Mods, 9/26/22 completed, 10/7 shipped, 11/3/22 delivery
