Time for new tires

JuztDave
Nov 06, 2024

Rank 0

Yesterday at 8:49 pm

I have 2021 Badlands non-sas with the stock tires, beadlock capable 285/70r17. I like the KO2 and want to stick with that tire but a larger size 315/70r17. My research says that I should be able to use the same rims for the larger tire, cany anyone confirm or has anyone does this? I will remove the crash bars and fix the speed-o-meter but is there anything else I need to account for when making this change?
2021 Cyper Orange 4 Door Badlands, LUX, Soft Top
Mods: HAVOC Rock Rails

Gladesmen

Yesterday at 9:15 pm

#1
do those wheels have the 55 offset or the 30mm offset if they are 55mm you might need to get some Good spacers, do not cheap out on these. then you should be good once you delete the crash bar. one thing to remember an Auto nosquatch badlands has different gearing than SAS so you might notice a difference. My buddy has a nosquatch badlands and he added wheels and 35's and he doesn't notice a difference in performance, other than millage.
Bronco Nation 1100. Everglades, Desert Sand
Res: 7/30/20 ordered 1/22/21 reorder 10/15/21 changed to Everglades 3/9/22 schedule 8/29/22 bumped to 9/5; 9/7/22 blend, 9/9 Mods, 9/26/22 completed, 10/7 shipped, 11/3/22 delivery
Deano Bronc

Rank 0

Yesterday at 9:20 pm

#2
Good question, is there an easy way for me to tell the offset? How does it come from the factory?
2021 Cyper Orange 4 Door Badlands, LUX, Soft Top
Mods: HAVOC Rock Rails

Gladesmen

Yesterday at 9:41 pm

#3
JuztDave
Good question, is there an easy way for me to tell the offset? How does it come from the factory?

I did a quick search and found the offset of all the other wheels but not the Beadlock capable nosquatch wheel. maybe someone can chime in and let us know that info. I will continue to look on my end

Edit : just found that it is: The Optional Badlands wheel is a 17 x 8” wheel, with 6 x 5.5” (or 6 x 139mm) with a 55mm offset and 6.66” of backspacing. So you will most likely need spacers. BORAs would be my choice probably 1.5" .
Bronco Nation 1100. Everglades, Desert Sand
Res: 7/30/20 ordered 1/22/21 reorder 10/15/21 changed to Everglades 3/9/22 schedule 8/29/22 bumped to 9/5; 9/7/22 blend, 9/9 Mods, 9/26/22 completed, 10/7 shipped, 11/3/22 delivery
